Use canvas to add shadow to control


Post new topic   Reply to topic    Cheat Engine Forum Index -> Cheat Engine Lua Scripting
View previous topic :: View next topic
Author Message
.lua
Expert Cheater
Reputation: 0

Joined: 13 Sep 2018
Posts: 120

PostPosted: Tue Jan 21, 2020 11:23 am    Post subject: Use canvas to add shadow to control Reply with quote

This is a blurred shadow painted on the canvas, it has no transparency, I can adjust the position and size. Can you help me optimize it? I know there are many problems with this code
Code:
if f then f.Destroy() end
f=createForm()
f.BorderStyle='bsSizeable'
f.Color=0xff
f.setSize(400,350)
f.setPosition(330,50)

p1=createPanel(f)
p1.setSize(100,100)
p1.setPosition(50,70)
p1.BevelOuter='bvNone'
p1.color=0xffff

p2=createPanel(f)
p2.setSize(100,100)
p2.setPosition(230,70)
p2.BevelOuter='bvNone'
p2.color=0xffff00

p3=createPanel(f)
p3.setSize(100,100)
p3.setPosition(50,200)
p3.BevelOuter='bvNone'
p3.color=0xff00ff

function setShadow(form,control)
  local v=5
  local size=40
  local L=control.Left
  local T=control.Top
  local W=control.Width
  local H=control.Height
  form.OnPaint=function()
    form.Canvas.Clear()
    for j=1,size do
    form.Canvas.Pen.Color=form.color-j*v
      for i=1,size-j*2 do
        form.Canvas.Pen.Width=i--i+W/2
        form.Canvas.roundRect(L,T,L+W,T+H,10,10)
      end
    end
  end form.repaint()
end
setShadow(f,p3)
--setShadow(f,p2)
--setShadow(f,p3)
I changed some more code. It can now be displayed around the control. You'd better optimize the code again

Last edited by .lua on Wed Jan 22, 2020 12:18 am; edited 2 times in total
Back to top
View user's profile Send private message
Corroder
Grandmaster Cheater Supreme
Reputation: 33

Joined: 10 Apr 2015
Posts: 1309

PostPosted: Tue Jan 21, 2020 6:25 pm    Post subject: Reply with quote

First, sorry if out of topic and I don't know if roundRect() shall work in code below, but for a object shadow I am use something like this.

Code:
if f then f.Destroy() end

f=createForm()
f.BorderStyle='bsSizeable'
f.Color=0x0ff
f.setSize(400,250)
f.setPosition(330,50)

p1=createPanel(f)
p1.setSize(100,100)
p1.setPosition(50,70)
p1.BorderStyle = 'bsNone'
p1.color=0xffff

bmp = createBitmap()
bmp.Width = p1.Width + 20
bmp.Height = p1.Height + 40
bmp.Left = p1.Top - 30
bmp.Top = p1.Top - 30
bmp.Canvas.gradientFill(0,10,bmp.width,bmp.height, 0x0000FF,0x000CCC,1)    -- Adjust shadow effect here

pbx = createPaintBox(f)
pbx.Width = p1.Width + 20
pbx.Height = p1.Height + 40
pbx.Top= p1.Left - 10
pbx.Left= p1.Top - 30

Bitmap = createBitmap(pbx.Width, pbx.Height)
Bitmap.TransparentColor = 0
Bitmap.Transparent = true

local function updateBitM()
 Bitmap.Canvas.clear();
 Bitmap.Canvas.roundRect(0,0,pbx.Width,pbx.Height);
 Bitmap.Canvas.Draw(0,0, bmp)
 local t=createBitmap()
 t.Canvas.Brush.Color=0x00 --0xffffff
 t.Canvas.Pen.Color=0xffffff
 t.transparent=true
 t.TransparentColor=0xffff00
 t.Width=120
 t.Height=20
 t.Top=10
 t.Left=15
 Bitmap.Canvas.Draw(0,0,t)   -- change 0,0 as coordinate to get effect
 t.destroy()
end

pbx.onPaint = function ()
updateBitM()
pbx.Canvas.clear()
pbx.Canvas.draw(0,0,Bitmap);
local r = pbx.Canvas.getClipRect();
pbx.Canvas.drawWithMask(r.Left,r.Top,r.Right, r.Bottom,Bitmap,r.Left, r.Top,r.Right,r.Bottom)
end

pbx.onClick = function ()
pbx.repaint()
end

_________________
Stealing Code From Stolen Code...
And Admit It.. Hmmm....Typically LOL
Back to top
View user's profile Send private message
Aylin
Grandmaster Cheater
Reputation: 8

Joined: 16 Feb 2017
Posts: 570

PostPosted: Wed Jan 22, 2020 2:46 am    Post subject: Reply with quote

Why are you dealing with complex codes? Smile
Sometimes simple codes can save time and code. Wink

Idea Idea Idea
Code:
if f then f.Destroy() end

f=createForm()
f.BorderStyle='bsSizeable'
f.Color=0x0ff
f.setSize(400,250)
f.setPosition(330,50)

p1=createPanel(f)
p1.setSize(100,100)
p1.setPosition(50,70)
p1.BorderStyle = 'bsNone'
p1.color=0xffff

p2=createPanel(f)
p2.setSize(100,100)
p2.setPosition(240,70)
p2.BorderStyle = 'bsNone'
p2.color=0xff22

l1=createLabel(f)
l1.setPosition(100,200)
l1.Font.Style = "fsBold"
l1.Font.Size = 10
--l1.Color = 0x0000CC
l1.caption = "Example  Shadow"
l1.Font.color=0xffff
l1.bringToFront()

function Shadow1(f, shdPan, Left, Top)
local p3=createPanel(f)
p3.Width = shdPan.Width
p3.Height = shdPan.Height
p3.Left = shdPan.left - Left
p3.Top = shdPan.Top - Top
p3.BorderStyle = 'bsNone'
p3.color=0x00009C
p3.BevelOuter = "bvNone"
p3.sendToBack()
end

Shadow1(f, p1, 10, 10)
Shadow1(f, p2, 10, 10)
Shadow1(f, l1, 4, 4) --Label will not work effectively

----------------------------------------------------

@Corroder code works fine, but for more panels, it is necessary to rewrite the code again and again.

Code:
if f then f.Destroy() end

f=createForm()
f.BorderStyle='bsSizeable'
f.Color=0x0ff
f.setSize(400,250)
f.setPosition(330,50)

p1=createPanel(f)
p1.setSize(100,100)
p1.setPosition(50,70)
p1.BorderStyle = 'bsNone'
p1.color=0xffff

p2=createPanel(f)
p2.setSize(100,100)
p2.setPosition(240,70)
p2.BorderStyle = 'bsNone'
p2.color=0xff22

bmp = createBitmap()
bmp.Width = p1.Width
bmp.Height = p1.Height + 20
bmp.Left = p1.left - 30
bmp.Top = p1.Top - 30
bmp.Canvas.gradientFill(0,10,bmp.width,bmp.height, 0x00008F,0x0000CC,1)    -- Adjust shadow effect here

pbx = createPaintBox(f)
pbx.Width = p1.Width -- + 20
pbx.Height = p1.Height + 20
pbx.Top= p1.Top - 30
pbx.Left= p1.Left - 10

------------------------------
bmp1 = createBitmap()
bmp1.Width = p2.Width
bmp1.Height = p2.Height + 20
bmp1.Left = p2.left - 30
bmp1.Top = p2.Top - 30
bmp1.Canvas.gradientFill(0,10,bmp1.width,bmp1.height, 0x00008F,0x0000CC,1)    -- Adjust shadow effect here

pbx1 = createPaintBox(f)
pbx1.Width = p2.Width -- + 20
pbx1.Height = p2.Height + 20
pbx1.Top= p2.Top - 30
pbx1.Left= p2.Left - 10
--------------------------------

Bitmap = createBitmap(pbx.Width, pbx.Height, pbx1.Width, pbx1.Height)
Bitmap.TransparentColor = 0
Bitmap.Transparent = true

local function updateBitM()
 Bitmap.Canvas.clear();
 Bitmap.Canvas.roundRect(0,0,pbx.Width,pbx.Height,pbx1.Width,pbx1.Height);
 Bitmap.Canvas.Draw(0,0, bmp)
 Bitmap.Canvas.Draw(0,0, bmp1)
 local t=createBitmap()
 t.Canvas.Brush.Color=0x00 --0xffffff
 t.Canvas.Pen.Color=0xffffff
 t.transparent=true
 t.TransparentColor=0xffff00
 t.Width=120
 t.Height=20
 t.Top=10
 t.Left=15
 Bitmap.Canvas.Draw(0,0,t)   -- change 0,0 as coordinate to get effect
 t.destroy()
end

pbx.onPaint = function ()
updateBitM()
pbx.Canvas.clear()
pbx.Canvas.draw(0,0,Bitmap);
local r = pbx.Canvas.getClipRect();
pbx.Canvas.drawWithMask(r.Left,r.Top,r.Right, r.Bottom,Bitmap,r.Left, r.Top,r.Right,r.Bottom)
end

pbx1.onPaint = function ()
updateBitM()
pbx1.Canvas.clear()
pbx1.Canvas.draw(0,0,Bitmap);
local r1 = pbx1.Canvas.getClipRect();
pbx1.Canvas.drawWithMask(r1.Left,r1.Top,r1.Right, r1.Bottom,Bitmap,r1.Left, r1.Top,r1.Right,r1.Bottom)
end

pbx.onClick = function ()
pbx.repaint()
pbx1.repaint()
end


Of course, the final decision is yours.

_________________
Hi Hitler Take control of your trainer
Enthusiastic people: Always one step ahead
Do not underestimate me Master: You were a beginner in the past
Back to top
View user's profile Send private message MSN Messenger
.lua
Expert Cheater
Reputation: 0

Joined: 13 Sep 2018
Posts: 120

PostPosted: Wed Jan 22, 2020 3:00 am    Post subject: Reply with quote

Aylin wrote:
Why are you dealing with complex codes? Smile
Sometimes simple codes can save time and code. Wink
I want the control to have a fuzzy projection。As shown in the figure


 Description:
 Filesize:  22.78 KB
 Viewed:  646 Time(s)



Back to top
View user's profile Send private message
Aylin
Grandmaster Cheater
Reputation: 8

Joined: 16 Feb 2017
Posts: 570

PostPosted: Wed Jan 22, 2020 5:22 am    Post subject: Reply with quote

and I still believe in the magic of simple codes.
Open the limit of your imagination. Wink

Code:
if f then f.Destroy() end

f=createForm()
f.BorderStyle='bsSizeable'
f.Color=0x0ff
f.setSize(400,250)
f.setPosition(330,50)

p1=createPanel(f)
p1.setSize(300,70)
p1.setPosition(50,20)
p1.BorderStyle = 'bsNone'
p1.color=0xffff

p2=createPanel(f)
p2.setSize(300,70)
p2.setPosition(50,130)
p2.BorderStyle = 'bsNone'
p2.color=0xff22

l1=createLabel(f)
l1.setPosition(100,230)
l1.Font.Style = "fsBold"
l1.Font.Size = 10
--l1.Color = 0x0000CC
l1.caption = "Example  Shadow"
l1.Font.color=0xffff
l1.bringToFront()

function Shadow1(f, shdPan, Left, Top)
local i3=createImage(f)
i3.Width = shdPan.Width
i3.Height = shdPan.Height
i3.Left = shdPan.left + Left
i3.Top = shdPan.Top + Top
i3.AutoSize=false
i3.Stretch=true
i3.picture.loadFromStream(findTableFile("shadw03.png").stream)
i3.sendToBack()
end

Shadow1(f, p1, 0, 10)
Shadow1(f, p2, 0, 10)
Shadow1(f, l1, 0, 1) --Label will not work effectively


and Shadow 2:

Code:
function Shadow2(f, shdPan, Left, Top)
local i4=createImage(f)
i4.Width = shdPan.Width + 60
i4.Height = shdPan.Height + 60
i4.Left = shdPan.left + Left
i4.Top = shdPan.Top + Top
i4.AutoSize=false
i4.Stretch=true
i4.picture.loadFromStream(findTableFile("shadw05.png").stream)
i4.sendToBack()
end
Shadow2(f, p2, -30, -30)



 Description:
 Filesize:  65.38 KB
 Viewed:  638 Time(s)




 Description:
 Filesize:  35.81 KB
 Viewed:  638 Time(s)




 Description:
 Filesize:  52.14 KB
 Viewed:  638 Time(s)




_________________
Hi Hitler Take control of your trainer
Enthusiastic people: Always one step ahead
Do not underestimate me Master: You were a beginner in the past
Back to top
View user's profile Send private message MSN Messenger
Corroder
Grandmaster Cheater Supreme
Reputation: 33

Joined: 10 Apr 2015
Posts: 1309

PostPosted: Wed Jan 22, 2020 6:05 am    Post subject: Reply with quote

Aylin wrote:

@Corroder code works fine, but for more panels, it is necessary to rewrite the code again and again.


Okay, then I just see this word on the post title, he said 'CANVAS' not use 'IMAGE' as object shadow. So, I give an example using canvas for object shadow.
and "it is necessary to rewrite the code again and again", of course not, because I believe if someone knows about Lua scripting, he able to create a Lua function for the general object purpose from my example code above. That's it.

_________________
Stealing Code From Stolen Code...
And Admit It.. Hmmm....Typically LOL
